ACiQ Essentials K-32 - Features At A Glance
ACiQ Essentials K-32 Series 18,000 BTU Single-Zone Ductless Mini Split Heat Pump System - 20 SEER2 - R32 | 230V White Wall Mount
The ACiQ Essentials K-32 Series 18,000 BTU Single-Zone Ductless Mini Split Heat Pump System - 20 SEER2 - R32 | 230V White Wall Mount pairs the ACiQ Essentials K-32 18,000 BTU outdoor heat pump condenser (ACIQ-K18Z-32-HP230B) with a white wall-mounted indoor air handler (ACIQ-K18W-W-32-HP230B) for ductless heating and cooling of one room or zone. It is the R32, 20 SEER2 generation of the ACiQ Essentials single-zone line, with built-in Wi-Fi and a 16 ft line set in the box.
Sized for spaces of roughly 600 to 1,000 sq ft, depending on insulation, window exposure, ceiling height and climate. Rated cooling from 5°F to 127°F outdoor and heating down to -4°F.
System Includes
- Outdoor heat pump condenser: ACIQ-K18Z-32-HP230B
- Wall-mounted indoor air handler (white): ACIQ-K18W-W-32-HP230B
- Application: single-room ductless heating and cooling
Key Features
- 20 SEER2 / 8.5 HSPF2 inverter heat pump: heats and cools from one system.
- Built-in Wi-Fi on the wall unit: control from the ACiQ app, Amazon Alexa or Google Assistant, no add-on module needed.
- 16 ft line set included; the condenser is pre-charged for a 16 ft run.
- Quiet operation: indoor unit as low as 32 dBA, outdoor 55 dBA.
- Gold Fin coated coil, self-cleaning function, sleep, eco, turbo and timer modes on the included remote.
- 6-year compressor / 4-year parts warranty with online registration.
What's In The Box
- 1 ACIQ Essentials Condenser
- 1 ACIQ Essentials Air Handler in White
- 1 ACIQ Essentials Remote Control
- Rubber Feet
- Plasticene
- Mounting Plate
- Plastic Wrap
- Screws (Short)
- Drain Elbow
- Drain Lines
- 2 AAA Batteries
- 16 foot Line Set (Not Precharged)
- Wall Cap
- Anchors
- Power Cords
- Screws (Long) Control Wire
Product Details
| Brand | ACiQ |
| Series | ACiQ Essentials K-32 Series (R32, 20 SEER2) |
| System Type | Single-Zone ductless mini split heat pump |
| Outdoor Model | ACIQ-K18Z-32-HP230B |
| Indoor Model(s) | ACIQ-K18W-W-32-HP230B |
| Nominal Outdoor Capacity | 18,000 BTU |
| Indoor Zone Sizes | 18k |
| Voltage | 230V |
| Refrigerant | R32 |
| Indoor Style | White wall mount |
| Replaces | ACIQ-K18Z-HP230B / ACiQ-K18W-HP230 ACIQ-K18W-W-HP230B |
Before You Buy
- Professional installation is recommended for proper sizing, refrigerant handling, wiring, vacuuming and startup. This is not a quick-connect DIY system.
- Confirm breaker size (20 Amps maximum), wiring, line-set routing, clearances and local code requirements before installation.
- Register the system online after installation to activate the 6-year compressor / 4-year parts warranty.
Model Combination: ACIQ-K18Z-32-HP230B - ACIQ-K18W-W-32-HP230B
